AP 25T

AP 25T

The AP 25T Aerial Work Platform is a powerful telescopic boom lift engineered to provide safe, stable, and efficient access to elevated work areas up to 25 metres. Featuring a rugged chassis, advanced hydraulic system, and precision controls, the AP 25T delivers exceptional performance for construction, industrial maintenance, infrastructure projects, and facility management. Its high reach, excellent horizontal outreach, and superior maneuverability make it the ideal solution for demanding work-at-height applications.

Description

The AP 25T Aerial Work Platform is a powerful telescopic boom lift engineered to provide safe, stable, and efficient access to elevated work areas up to 25 metres. Featuring a rugged chassis, advanced hydraulic system, and precision controls, the AP 25T delivers exceptional performance for construction, industrial maintenance, infrastructure projects, and facility management. Its high reach, excellent horizontal outreach, and superior maneuverability make it the ideal solution for demanding work-at-height applications.

Specification Value
Model AP 25T
Machine Type Self-Propelled Telescopic Boom Lift
Maximum Working Height 25.0 m
Maximum Platform Height 23.0 m
Maximum Horizontal Outreach 17.5 m
Platform Capacity 300 kg
Platform Size (L × W) 2.44 × 0.91 m
Maximum Occupants 2 Persons
Boom Type Telescopic Boom
Turret Rotation 360° Continuous
Platform Rotation ±90°
Jib Rotation 135°
Drive Type 4WD
Power Source Diesel Engine
Travel Speed (Stowed) 5.5 km/h
Travel Speed (Raised) 1.0 km/h
Gradeability 45%
Ground Clearance 320 mm
Tyres Foam-Filled Rough Terrain Tyres
Overall Length 11.2 m
Overall Width 2.50 m
Overall Height 2.80 m
Wheelbase 2.80 m
Machine Weight 16,500 kg
Hydraulic Tank Capacity 150 L
Fuel Tank Capacity 150 L
Control System Electro-Hydraulic Proportional Controls
Emergency Lowering System Standard
Tilt Alarm Standard
Emergency Stop Standard
  • 25 m maximum working height
  • Heavy-duty telescopic boom
  • Excellent horizontal outreach
  • 360° continuous rotation
  • Four-wheel drive (4WD)
  • Oscillating axle for rough terrain
  • Proportional hydraulic controls
  • Automatic platform leveling
  • Emergency lowering system
  • Tilt protection system
  • High-capacity work platform
  • Low-maintenance design
  • Reliable safety features
  • Suitable for indoor and outdoor applications
